The GESC Series Flip-Flow Screen is designed for efficient screening of wet, sticky, and difficult-to-screen materials, especially in C&D waste recycling. Combining circular and elliptical vibrations with a single drive, its polyurethane elastic screen continuously expands and contracts to deliver high-intensity screening action, reducing screen blockage and improving separation efficiency.
With few rotating components, it offers reliable operation, low maintenance, and long service life. Bolt-free screen panels enable quick replacement, while rubber springs help reduce vibration and noise. Adjustable amplitude and optimized screen angles ensure stable screening performance for demanding applications. Available in multiple models and configurations, the Flip-Flow Screen can be customized for different capacities and screening sizes. It can operate independently or integrate with shredders, crushers, conveyors, and sorting equipment to form a complete recycling system. Contact GEP ECOTECH now for a tailored screening solution.
Continuous stretching and relaxing of polyurethane screen panels effectively prevents clogging when processing wet and sticky materials.
Elastic polyurethane panels provide strong vibration and deformation, improving screening efficiency while maintaining reliable long-term performance.
Combined circular and elliptical vibrations enhance material movement, delivering efficient and consistent separation across challenging screening applications.
Adjustable vibration amplitude and screening parameters allow flexible adaptation to different materials, capacities, and separation requirements.
Fewer rotating components reduce maintenance requirements, while durable screen panels support reliable operation and extended service life.
Modular screen panels enable convenient replacement, minimizing maintenance downtime and keeping the screening process running efficiently.
| Model | Screen Surface Dimensions（mm） | Number of Layers | Inclination (°) | Screening Particle Size (mm) | Power (kW) | Capacity (t/h) |
| GESC1340 | 1300×4000 | 1 | 5–20 | 2–20 | 7.5 | 0–50 |
| GESC1340 | 1300×4000 | 2 | 2–100 | 11 | 0–50 | |
| GESC1650 | 1600×5000 | 1 | 2–25 | 11 | 0–100 | |
| GESC1650 | 1600×5000 | 2 | 2–100 | 18.5 | 0–100 | |
| GESC2050 | 2000×5000 | 1 | 2–25 | 18.5 | 0–150 | |
| GESC2050 | 2000×5000 | 2 | 2–100 | 22 | 0–150 | |
| GESC2260 | 2200×6000 | 1 | 2–30 | 22 | 0–200 | |
| GESC2260 | 2200×6000 | 2 | 2–100 | 30 | 0–200 | |
| GESC2560 | 2500×6000 | 1 | 2–30 | 30 | 0–250 | |
| GESC2560 | 2500×6000 | 2 | 2–100 | 37 | 0–250 |
Note: Technical specifications may change without notice due to ongoing technological advancements.
