The GVF Series Vibrating Feeder is designed to provide stable, controlled, continuous material flow for production lines. Its dual-eccentric-shaft excitation system generates strong, uniform vibration, preventing bridging and clogging while ensuring smooth feeding from storage hoppers to crushers, screens, conveyors, etc. Adjustable excitation force and optimized trough geometry deliver even material distribution, reduce sudden surges and protect downstream equipment from overload while maintaining consistent feeding efficiency.
Suitable for aggregates, ores, solid waste, biomass and industrial feedstock, the GVF Series performs reliably in demanding applications. Its compact structure, few wear parts and optional sealing reduce maintenance, dust and noise. Easy installation and flexible configuration ensure long-term operational stability under heavy continuous working conditions, minimizing unplanned downtime, extending equipment service life and maintaining efficient, predictable material flow. Contact us now for a customized design.
Adopting double eccentric shafts as the excitation source, the amplitude is stable, the continuity is good, and the excitation force is adjustable, which can ensure the fluidity of the material.
Minimal rotating parts, fewer wear-parts, low capital investment and energy consumption.
Stable operation without material backflow; easy to adjust, install, and maintain.
The excitation force can be tuned to match different material characteristics and feed rates.
Operates quietly; optional enclosed design helps contain dust and improve the working environment.
Uses vibration principle to feed materials evenly and continuously from storage hopper into downstream equipment.
| Model | Chute Size(W×L) (mm) | Max. Feeding Size (mm) | Capacity (t/h) | Power (kW) | Dimension (L×W×H) (mm) |
| GVF8530 | 850×3000 | 400 | 80-120 | 7.5 | 3110×1800×1600 |
| GVF9638 | 960×3800 | 500 | 120-210 | 11 | 3850×1950×1600 |
| GVF1142 | 1100×4200 | 580 | 200-430 | 15 | 4400×2050×1660 |
| GVF1149 | 1100×4900 | 580 | 280-500 | 15 | 5200×2050×1700 |
| GVF1349 | 1300×4900 | 650 | 450-600 | 22 | 5200×2350×1750 |
| GVF1560 | 1500×6000 | 800 | 500-700 | 30 | 6082×2580×2083 |
Note: Technical specifications may change without notice due to ongoing technological advancements.
